LiPo/Li-ion/LiFe battery balance Charger

Chargery released Balance charger and discharger which is applied to 1 to 10S lipo, Lion, LiFe cells, NIMH&NICD, and Pb battery (VRLA, lead battery).

Chargery improved the voltage accuracy to under 5mV even up to 10S lipo cells, that help us to protect and manage each cell voltage during charge and discharge.

Unique balance algorithm realize up to 1.3A current draw from each cell

Creative circuit topology realize response quickly to any instantaneously changes on input and output voltage.

Released model: 320B, 5006B, 5008B, 50010B

Chargery 5006B,5008B,50010B Series charger uses advanced Synchronous buck-boost DC/DC converter
technology, high power, high current and high-performance power conversion circuit. The maximum charge
power up to 500W, the maximum charge/discharge current is up to 20A. The charger can charge up to 10S LiPo,
Lilo, LiFe, with maximum 1.3A balance current



MODEL: 50010B, 5008B, 5006B

Features:

  1. Unique charge architecture make the charger response quickly to any changes of voltage on input and output.
  2. The charger use advanced ADC measurement technology, high accuracy, high voltage and high current detection circuit. The maximum voltage measurements tolerance is within 5mV at up to 10S LiPo battery.
  3. The charger adopts advance balance circuit and Algorithm, constant 1.3A per cell balance current is very useful for large capacity battery pack, the feature can resume all cell voltage balance status at the shortest time.
  4. Over temperature protection make sure the system safety during balance.
  5. Charger internal temperature protection. When the internal temperature exceeds the reduce temperature,
    the output power is automatically decreased; and the charger will stop working when temperature exceeds
    the shut-down temperature.
  6. Intelligent fan control circuit sense internal temperature via temperature sensor, to thereby control the fan speed.
  7. TFT LCD screen provides rich information including current, voltage, power, capacity, time, working status
    and temperature and so on.
  8. The charger features a maximal safety protection,
    Reversed polarity protection on input and output,
    Anti-spark on input and output
  9. Wrong battery pack connection protection when multi battery pack connected in series on adapter
    board.
  10. Charge time, charge capacity and battery temperature protection
  11. Supports upgrading the firmware program by USB port.

Specifications:

  1. Input voltage: DC 10-28V, 30V max.
  2. Charge current: 0.1-20A, 500W max.
  3. Discharge Current: 0.1-10A, 35W max.
  4. Accuracy of the cell voltage: -5mV/+5mV
  5. Balance current: 1.3A per cell only for LiPoly, Li-ion and LiFePO4 battery pack
  6. Battery Type: LiPoly, Li-ion, LiFePO4, NiMh/NiCd, Pb acid(VRLA) battery pack
  7. Size154*114*33 (LWH, mm) or 6.14.481.3 (LWH, inch)
  8. Weight: 680g





50010B
50010B
50010B
5008B
5008B
50010B
5006B


MODEL: 320B

  1. 2S-3S LiPO
  2. 2A charge current
  3. 300mA balance current
  4. Voltage accuracy:10mV



320B user's manual v1.1(106K )




Safety Certification: CE

All products are fully committed to compliance with the European Unions RoHS directive.


Input and Output power leads have top quality and perfect conductive performance.
Input power lead ( standard)
 Output power lead -- 4mm banana with alligator clips(standard)
input power leads out power leads
4mm banana with Deans plug 4mm banana with JST plug 4mm banana with TAMIYA plug
4mm gold banana to DEANS plug 4mm gold banana to JST plug 4mm gold banana to TAMIYA plug
