 High Rate LiPo Battery |
|
| Some electric devices have to be driven with very large current, such as EV, R/C airplane, helicopters, car and boats, and electric tools etc. |
 |
| The battery capable of discharging at no less than 5C is called "High Rate Battery" . |
| High Rate LiPo Battery made by CHARGERY is mainly applied to R/C model, Electronic Vehicle and power tools. |
| The output connector of the battery pack can be customized. what you need is to tell us the number on the right photo. If there is no what you want, fell free to email us. |
 |
| The following models are mainly applied to R/C model, these models are one part of our products, and customized capacity and size could be available upon your requests. For detailed specifications, please contact us. |
| |
|
| Chargery power "CREST" series LiPo battery pack |
|
The "CREST" series battery is very strong, it can discharge continuously at 20C-22C, and the maximal discharge current even reaches 40C.
The series of battery pack can be charged at up to 4C.
|
Model |
Normal Voltage /V |
Rated Capacity/mAh |
Connector |
Size /mm |
Weight /g |
Charger Model |
Length |
Width |
Thickness |
PC360-2S |
7.4 |
360 |
3 PIN |
52 |
30 |
8.0 |
27 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
PC360-3S |
11.1 |
360 |
4 PIN |
52 |
30 |
11.5 |
35.5 |
| |
PC450-2S |
7.4 |
450 |
3 PIN |
52 |
30 |
8.6 |
33 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
PC450-3S |
11.1 |
450 |
4 PIN |
52 |
30 |
13.0 |
44.5 |
| |
PC800-2S |
7.4 |
800 |
3 PIN |
73 |
25 |
12.5 |
50 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
PC800-3S |
11.1 |
800 |
4 PIN |
73 |
25 |
18.0 |
70 |
| |
PC1000-2S |
7.4 |
1000 |
3 PIN |
72 |
34 |
12 |
60 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
PC1000-3S |
11.1 |
1000 |
4 PIN |
72 |
34 |
17 |
85 |
| |
PC1300-2S |
7.4 |
1300 |
3 PIN |
72 |
35 |
12.6 |
71 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
PC1300-3S |
11.1 |
1300 |
4 PIN |
72 |
35 |
18.9 |
99 |
PC1300-4S |
14.8 |
1300 |
5 PIN |
72 |
35 |
25.2 |
125 |
PC1300-5S |
18.5 |
1300 |
6 PIN |
72 |
35 |
31.5 |
150 |
PC1300-6S |
22.2 |
1300 |
7 PIN |
72 |
35 |
37.8 |
178 |
| |
PC1500-2S |
7.4 |
1500 |
3 PIN |
88 |
35 |
12 |
91 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
PC1500-3S |
11.1 |
1500 |
4 PIN |
88 |
35 |
18 |
129 |
PC1500-4S |
14.8 |
1500 |
5 PIN |
88 |
35 |
24 |
169 |
PC1500-5S |
18.5 |
1500 |
6 PIN |
88 |
35 |
30 |
208 |
PC1500-6S |
22.2 |
1500 |
7 PIN |
88 |
35 |
36 |
246 |
| |
PC1800-2S |
7.4 |
1800 |
3 PIN |
102 |
35 |
12 |
97 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
PC1800-3S |
11.1 |
1800 |
4 PIN |
102 |
35 |
18 |
138 |
PC1800-4S |
14.8 |
1800 |
5 PIN |
102 |
35 |
24 |
179 |
PC1800-5S |
18.5 |
1800 |
6 PIN |
102 |
35 |
30 |
219 |
PC1800-6S |
22.2 |
1800 |
7 PIN |
102 |
35 |
36 |
261 |
| |
PC2000-2S |
7.4 |
2000 |
3 PIN |
75 |
45 |
16.6 |
109 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
|
11.1 |
2000 |
4 PIN |
75 |
45 |
24.9 |
156 |
|
14.8 |
2000 |
5 PIN |
75 |
45 |
33.2 |
203 |
|
7.4 |
6000 |
3 PIN |
75 |
45 |
52 |
297 |
PC2000-3S2P |
11.1 |
4000 |
4 PIN |
75 |
45 |
52 |
297 |
| |
PC2200-2S |
7.4 |
2200 |
3 PIN |
102 |
35 |
14 |
112 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
|
11.1 |
2200 |
4 PIN |
102 |
35 |
21 |
160 |
|
14.8 |
2200 |
5 PIN |
102 |
35 |
28 |
209 |
|
18.5 |
2200 |
6 PIN |
102 |
35 |
35 |
256 |
PC2200-6S |
22.2 |
2200 |
7 PIN |
102 |
35 |
42 |
306 |
| |
PC2500-2S |
7.4 |
2500 |
3 PIN |
102 |
35 |
16 |
125 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
|
11.1 |
2500 |
4 PIN |
102 |
35 |
25 |
180 |
|
14.8 |
2500 |
5 PIN |
102 |
35 |
33 |
235 |
|
18.5 |
2500 |
6 PIN |
102 |
35 |
41 |
290 |
PC2500-6S |
22.2 |
2500 |
7 PIN |
102 |
35 |
50 |
345 |
| |
PC3300-2S |
7.4 |
3300 |
3 PIN |
135 |
45 |
12.4 |
170 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
|
11.1 |
3300 |
4 PIN |
135 |
45 |
18.6 |
245 |
|
14.8 |
3300 |
5 PIN |
135 |
45 |
24.8 |
320 |
|
18.5 |
3300 |
6 PIN |
135 |
45 |
31 |
395 |
PC3300-6S |
22.2 |
3300 |
7 PIN |
135 |
45 |
37.2 |
470 |
| |
PC3700-2S |
7.4 |
3700 |
3 PIN |
135 |
45 |
15 |
170 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
|
11.1 |
3700 |
4 PIN |
135 |
45 |
22.5 |
275 |
|
14.8 |
3700 |
5 PIN |
135 |
45 |
30 |
360 |
|
18.5 |
3700 |
6 PIN |
135 |
45 |
37.5 |
445 |
PC3700-6S |
22.2 |
3700 |
7 PIN |
135 |
45 |
45 |
530 |
| |
PC4500-2S |
7.4 |
4500 |
3 PIN |
166 |
45 |
15.6 |
234 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
|
11.1 |
4500 |
4 PIN |
166 |
45 |
22.5 |
341 |
|
14.8 |
4500 |
5 PIN |
166 |
45 |
29.3 |
448 |
|
18.5 |
4500 |
6 PIN |
166 |
45 |
36 |
555 |
PC4500-6S |
22.2 |
4500 |
7 PIN |
166 |
45 |
46 |
662 |
| |
PC5000-2S |
7.4 |
5000 |
3 PIN |
166 |
45 |
18 |
258 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
|
11.1 |
5000 |
4 PIN |
166 |
45 |
27 |
377 |
|
14.8 |
5000 |
5 PIN |
166 |
45 |
35 |
496 |
|
18.5 |
5000 |
6 PIN |
166 |
45 |
45 |
615 |
PC5000-6S |
22.2 |
5000 |
7 PIN |
166 |
45 |
54 |
734 |
| |
PC6000-2S |
7.4 |
6000 |
3 PIN |
166 |
45 |
21 |
306 |
320B, 550B, 620B, 630B, 680B, 680B+, 1010B |
|
11.1 |
60200 |
4 PIN |
166 |
45 |
31 |
449 |
|
14.8 |
6000 |
5 PIN |
166 |
45 |
43 |
592 |
|
18.5 |
6000 |
6 PIN |
166 |
45 |
54 |
735 |
PC6000-6S |
22.2 |
6000 |
7 PIN |
166 |
45 |
64 |
878 |
|
|
|
|
|
|
|
|
|
Note: 320B, 620B, 550B, 630B, 680B, 680B+ and 1010B are balance charger.The battery has to be mounted with the balance connector to use the unit.
The battery weight includes the power leads and connector, it is estimated.
|
|
| |
|
|
