  home > Products and Solutions > LiPo/Li-ion Battery



High rate LiPo battery pack with hard case for 1/10 racing vehicle

NEW!! 50C 5500mAH 7.4V, 11.1V and 14.8V racing car Lipo battery is launched. Please download the 2010 racing car lipo battery catalog and datasheet for more information.

Ultra high performance 1/10 scale hard case LiPo battery pack. there are 25C, 35C and 50C and from 3700-5800mAh avaiable.

Chargery LiPo battery pack can be charged at up to 6C, 2C-3C is recommended. And longer cycle life up to over 200.

Features
  • Battery size is 137*46*24 (L*W*T, mm)
  • Weight is around 279g
  • Special developed for racing vehicle
  • 100% matched cells for Impendance, capacity and voltage
  • Meets and exceeds ROAR Sanctioning requirements
  • Embedded standard 4mm Gold connectors
  • 5.0 mOhm typical at the terminals!
  • Simple connection with Chargery chargers
  • Maintains 7.4V+ flat platform discharge performance under typical racing loads, for consistent power and precise control.
  • Replace with NIMH battery pack, without need for deep discharge cycling
  • 2C fast charge (with CY-0410B recommended)
  • Typical race consumes just 25-35% of capacity
  • Extremely slow self-discharge
  • Special balance charge extension wire for the battery pack.

PS5200-2S Datasheet(77.5K )

CPHE5000-2S Datasheet(113K )

CP2HE5500-2S2P Datasheet(147K ) CP2HE5500-4S2P Datasheet(146K )
CPE5000-2S Datasheet(96.5K ) CPL5000-2S Datasheet(77.5K )
The typical discharge curve at different rate ( Model: PS5200-2S)

  • CPS5200-2S, 7.4V 5200mAH, 25C continuously discharge, 50C burst
  • Embedded standard 4mm Gold connectors
  • 137*46*24 (L*W*T, mm)
  • Around 279g



  • CP2E5500-2S2P, 7.4V 5500mAH, 50C continuously discharge, 100C burst
  • with discharge cable and balance connector,
  • 137*46*25 (L*W*T, mm)
  • Around 300g

Model
Rated capacity
Voltage
Dimensions(mm)
Weight
Discharge rate
Charger Model
(mAH)
(V)
Thickness
Width
Length
(g)
Continuous
Burst
CP2HE5500-2S2P

5500

7.4
25.0
46.5
138
300
50C
100C
CP2HE5200-2S2P 5200
7.4
25.0
46.5
138
295
50C
100C
CP2HE4600-Saddle 4600
7.4
25.0
46.5
69.5
285
50C
100C
CP2HE5000-1S2P 5000 3.7 18.3 46.5 93 216 50C 100C

CPE5600-2S2P
5600
7.4
24.5
46.5
137.5
300
35C
70C
CPE5200-2S2P
5200
7.4
24.5
46.5
137.5
295
35C
70C

CPE4800-Saddle

4800
7.4
24.5
46.5
69.5
275
35C
60C
CPE3800-2S2P
3800
7.4
24.5
46.5
137.5
238
35C
60C
CPE5000-1S2P
5000
3.7
18.3
46.5
93.0
206
35C
60C
CPS5800-2S2P
5800
7.4
24.5
46.5
137.5
300
25C
50C
CPS5200-2S2P
5200
7.4
24.5
46.5
137.5
280
25C
50C
CPS5000-Saddle
5000
7.4
24.5
46.5
69.5
280
25C
50C
CPS3700-2S1P
3700
7.4
24.5
46.5
137.5
227
25C
50C
